PANDUIT BARB-TY™
Polyamide 6.6 cable ties with metal barb
Unlike one-piece standard ties, these two-piece cable ties have a stainless steel fastening barb for securing the strap.
PANDUIT BARB-TY™ product information
Unlike one-piece standard ties, these two-piece cable ties have a stainless steel fastening barb for securing the strap.
- Available in widths of 2.4 to 7.0 millimetres
- Max. bundle diameter 229mm
- Available in natural, weatherproof or heat-resistant polyamide
- 11 different colours available
- Easy workability, even by hand
- UL certification
Please browse through the extensive range of PANDUIT cable ties! In addition to standard cable ties, the range also includes cable ties with a fastening eye, anchor or labelling tab made from polyamide 6.6 available in natural, black and various other colours. Ties made from heat-stabilised and UV stabilised PA are available in many different versions. TEFZEL and HALAR ties and a wide range of steel ties are also available.
PANDUIT also offers a huge assortment of fasteners and many packaging suggestions.
Request a free copy of the catalogue!
PANDUIT BARB-TY™ Available dimensions (cable tie width 7.0 mm, curved strap with straight tip)
| Art. no. | Length in mm | Width in mm | Thickness in mm | Head height in mm | Head width in mm | Max. bundle dia. mm | Min. tensile strength N | Package sizes |
|---|---|---|---|---|---|---|---|---|
| BT1M | 102,00 | 2 | 0,90 | 4 | 4,4 | 23 | 80 | 100 / 1.000 |
| BT1.5M | 160,00 | 2 | 1,20 | 4 | 4,6 | 38 | 80 | 100 / 1.000 |
| BT2M | 201,00 | 2 | 1,20 | 4 | 4,6 | 51 | 80 | 100 / 1.000 |
| BT3M | 282,00 | 2 | 1,20 | 4 | 4,6 | 76 | 80 | 100 / 1.000 |
| BT4M | 361,00 | 2 | 1,20 | 4 | 4,6 | 102 | 80 | 100 / 1.000 |
| BT1.5I | 155,00 | 4 | 1,00 | 4,7 | 6,3 | 38 | 178 | 100 / 1.000 |
| BT2I | 203,00 | 4 | 1,00 | 4,7 | 6,3 | 51 | 178 | 100 / 1.000 |
| BT3I | 282,00 | 4 | 1,20 | 4,7 | 6,3 | 76 | 178 | 100 / 1.000 |
| BT4I | 363,00 | 4 | 1,20 | 4,7 | 6,3 | 102 | 178 | 100 / 1.000 |
| BT2S | 203,00 | 5 | 1,20 | 5,6 | 8,1 | 51 | 222 | 100 / 1.000 |
| BT3S | 305,00 | 5 | 1,30 | 5,6 | 8,1 | 76 | 222 | 100 / 1.000 |
| BT4S | 384,00 | 5 | 1,30 | 5,6 | 8,1 | 102 | 222 | 100 / 1.000 |
| BT2LH | 221,00 | 7 | 1,70 | 8,1 | 13,2 | 51 | 534 | 50 / 250 |
| BT3LH | 300,00 | 7 | 1,70 | 8,1 | 13,2 | 76 | 534 | 50 / 250 |
| BT4LH | 378,00 | 7 | 1,70 | 8,1 | 13,2 | 102 | 534 | 50 / 250 |
| BT5LH | 460,00 | 7 | 1,70 | 8,1 | 13,2 | 127 | 534 | 50 / 100 |
| BT6LH | 538,00 | 7 | 1,70 | 8,1 | 13,2 | 152 | 534 | 50 / 100 |
| BT7LH | 620,00 | 7 | 1,70 | 8,1 | 13,2 | 178 | 534 | 50 / 100 |
| BT8LH | 699,00 | 7 | 1,70 | 8,1 | 13,2 | 203 | 534 | 50 / 100 |
| BT9LH | 780,00 | 7 | 1,70 | 8,1 | 13,2 | 229 | 534 | 50 / 100 |
